Product Details
Manufacturer:
ZONCN
Model:
Z2000 SERIES
Warranty:
Origin:
Thượng Hải (CN)
Technical Specifications
- Senseless flux vector control (VC) V/F (Voltage/Frequency) Control
- Overload capacity is 60s for 150% of the rated current, 3s for 180% of the rated current.
- There are ten auxiliary frequency sources.
- It can implement fine tuning of auxiliary frequency and frequency synthesis
- Support PM motor (Z2000 T series)
- Power range：220V 0.4~7.5kW 380V 0.75~280kW
Package Includes
Import Information
HS Code:
Estimated Import Tax:
0,00
Customs Description
Mua Biến tần ZONCN Z2000 SERIES (0,4 ~ 280kW) chính hãng tại đại lý uy tín. Sản phẩm đa dạng công suất, đáp ứng mọi nhu cầu. Đảm bảo chất lượng, giá cả cạnh tranh.
| Model | Input Voltage(A) | Rated Output Power（kW) | Rated Input Current（A) | Rated Output Current（A） | Motor Equipped （kW) |
| Z2200-0R4G | 1PH AC220V ±15% | 0.4 | 5.4 | 2.4 | 0.4 |
| Z2200-0R75G | 1PH AC220V ±15% | 0.75 | 7.2 | 4.5 | 0.75 |
| Z2200-1R5G | 1PH AC220V ±15% | 1.5 | 10 | 7 | 1.5 |
| Z2200-2R2G | 1PH AC220V ±15% | 2.2 | 16 | 10 | 2.2 |
| Z2200-3R7G | 1PH AC220V ±15% | 3.7 | 23 | 16 | 3.7 |
| Z2200-5R5G | 1PH AC220V ±15% | 5.5 | 21 | 20 | 5.5 |
| Z2200-7R5G | 1PH AC220V ±15% | 7.5 | 31 | 30 | 7.5 |
| Z2400-0R7G | 3PH AC380V ±15% | 0.75 | 3.8 | 2.5 | 0.75 |
| Z2400-1R5G | 3PH AC380V ±15% | 1.5 | 5 | 3.7 | 1.5 |
| Z2400-2R2G | 3PH AC380V ±15% | 2.2 | 5.8 | 5 | 2.2 |
| Z2400-3R7G/5R5P | 3PH AC380V | 3.7/5.5 | 10/15.0 | 9.0/13 | 3.7/5.5 |
| Z2400-7R5P | 3PH AC380V | 5.5 | 15 | 13 | 5.5 |
| Z2400-7R5P | 3PH AC380V | 7.5 | 20 | 17 | 7.5 |
| Z2400-7R5G/11P | 3PH AC380V | 7.5/11 | 20/26 | 17/25 | 7.5/11 |
| Z2400-11G/15P | 3PH AC380V | 11/15.0 | 26/35 | 25/32 | 11/15.0 |
| Z2400-15G/18.5P | 3PH AC380V | 15/18.5 | 35/38 | 32/37 | 15/18.5 |
| Z2400-18.5G/22P | 3PH AC380V | 18.5/22 | 38/46 | 37/45 | 18.5/22 |
| Z2400-22G/30P | 3PH AC380V | 22/30 | 46/62 | 45/60 | 22/30 |
| Z2400-30G/37P | 3PH AC380V | 30/37 | 62/76 | 60/75 | 30/37 |
| Z2400-37G/45P | 3PH AC380V | 37/45 | 76/90 | 75/90 | 37/45 |
| Z2400-45G/55P | 3PH AC380V | 45/55 | 90/105 | 90/110 | 45/55 |
| Z2400-55G | 3PH AC380V | 55 | 105 | 110 | 55 |
