KEYSIGHT E36311A DC power supply, triple-output (6 V, 5 A & ±25 V, 1 A, 80 W)

Kết hợp này không tồn tại.

Điều khoản và điều kiện
Hoàn tiền trong 30 ngày
Giao hàng: Từ 2-3 ngày làm việc

Manufacturer:

KEYSIGHT

Model:

E36311A

Warranty:

Origin:

Malaysia

Power output: 80 W
Output Rating:
- Output 1: 0 to 6 V, 0 to 5 A
- Output 2: 0 to +25 V, 0 to 1 A
- Output 3: 0 to -25 V, 0 to 1 A
Ripple & Noise (20 Hz to 20 MHz)
- Normal Mode Voltage: <350 µVrms/ 2 mV p-p
- Normal mode current: <2 mA rms, <500 µA rms
Overvoltage protection (OVP): 0.20% +0.1V & 0.20% +0.4 V
Command processing time: < 10 ms
Accuracy 12 months (23 ºC ± 5 ºC)
- Current 0.1% +10 mA & 0.1% +4 mA
- Voltage 0.1% +5 mV & 0.05% +10 mV
AC input: AC 100- 230 V, 47- 63 Hz Interface: USB
includes over voltage, over current, and over temperature protection
Three independent outputs in one instrument saves maintenance cost and bench space
Display: 4.3-inch LCD color show the voltage and current of all three channels at the same time
