Product Details
Manufacturer:
KEYSIGHT
Model:
66311B
Warranty:
Origin:
Malaysia
Technical Specifications
- Output Ratings
- Voltage: 0 to 15 V
- Current: 0 to 3 A
- Peak Current for up to 7 ms: 5 A
- Programming accuracy at 25°C ±5°C
- Voltage: 0.05%+ 10 mV
- Current: 0.05%+ 1.33 mA
- DC Readback Accuracy
- Voltage: 0.03% + 5 mV
- Current (+20 mA to + rated current): 0.2% + 0.5 mA
- Current (-20 mA to – rated current): 0.2% + 1.1 mA
- Current (-20 mA to + 20 mA range): 0.1% + 2.5 µA
- Voltage: 0.05%+ 10 mV
- Transient Response
- 70 mV drop, <35 µs transient response time
Package Includes
Import Information
HS Code:
Estimated Import Tax:
0,00
Customs Description
- KEYSIGHT 66311B Mobile Communications DC Source (15V, 3A (GPIB))
