Nguồn một chiều DC Source KEYSIGHT 66311B (15V, 3A (GPIB))

Technical Specifications

• Output Ratings
  • Voltage: 0 to 15 V
  • Current: 0 to 3 A
  • Peak Current for up to 7 ms: 5 A
• Programming accuracy at 25°C ±5°C
  • Voltage: 0.05%+ 10 mV
    • Current: 0.05%+ 1.33 mA
  • DC Readback Accuracy
  • Voltage: 0.03% + 5 mV
  • Current (+20 mA to + rated current): 0.2% + 0.5 mA
  • Current (-20 mA to – rated current): 0.2% + 1.1 mA
  • Current (-20 mA to + 20 mA range): 0.1% + 2.5 µA
• Transient Response
  • 70 mV drop, <35 µs transient response time

Package Includes
