Product Details
Manufacturer:
HIOKI
Model:
3157
Warranty:
Origin:
Nhật Bản
Technical Specifications
| Tính năng cơ bản | AC 4-terminal method resistance measurement | |||||
|---|---|---|---|---|---|---|
| Hiển thị | Fluorescent tube (digital display) | |||||
| Dải dòng điện cài đặt | 3.0 A to 31.0 A AC (0.1 A resolution), into 0.1Ω load | |||||
| Công suất ngõ ra (MAX) | 130 VA (at output terminals) | |||||
| Open-terminal voltage | Max. 6 V AC | |||||
| Tần số | 50 Hz or 60 Hz sine wave (selectable) | |||||
| Dải đo điện trở | 0 to 1.800 Ω (0.001 Ω resolution), Accuracy: ±2% rdg. ±4 dgt. after zero-adjust | |||||
| Dải đo điện áp | 0 to 6.00 V AC (single range 0.01 V resolution), Accuracy: (1 % rdg. +5 dgt.) | |||||
| Monitor section | 0 to 35.0 A AC/ 0 to 6 V AC, Refresh rate: 2 times/s | |||||
| Timer display | Counts down time after start until preset time, Shows elapsed time after start | |||||
| Timer setting | 0.5 s to 999 s | |||||
| Comparator | PASS/FAIL evaluation using preset upper/lower limit, buzzer sound, signal output | |||||
| Bộ nhớ | Max. 20 settings (with save/load) | |||||
| Giao diện | EXT I/O, EXT SW, GP-IB or RS-232C (option) | |||||
| Power supply | 100 to 120 V/200 to 240 V AC (switching, 50/60 Hz) | |||||
Package Includes
Import Information
HS Code:
Estimated Import Tax:
0,00
