Rơ le thời gian (Timer) ABB CT-ERS.22S (1SVR730100R3300)

Technical Specifications

• Timer Relay Type:ON-Delay
• Time Range:0.05 s ... 300 h
• Rated Control Supply Voltage (Us):
  • 24 ... 240 V AC
  • 24 ... 48 V DC
• Rated Frequency (f):
  • 50 Hz
  • 60 Hz
  • DC
• Output:2 c/o (SPDT) contacts
• Terminal Type: Screw Terminals
• Rated Operational Current AC-12 (Ie):(230 V) 4 A
• Rated Operational Current AC-15 (Ie):(230 V) 3 A
• Rated Operational Current DC-12 (Ie):(24 V) 4 A
• Rated Operational Current DC-13 (Ie):(24 V) 2 A
• Minimum Switching Capacity:12 V, 10 mA
• Rated Impulse Withstand Voltage (Uimp):
  • Input Circuit 4 kV
  • Output Circuit 1 / Output Circuit 2 4 kV
• Rated Insulation Voltage (Ui):
  • Input Circuit / Output Circuit 500 V
  • Output Circuit 1 / Output Circuit 2 300 V
• Degree of Protection:Housing IP50
• Terminals IP20
• Overvoltage Category:III
• Pollution Degree:3
• Short-Circuit Protective Devices:
  • Output Circuit NC - F Type Fuses 6 A
  • Output Circuit NO - F Type Fuses 10 A
• Electrical Durability:AC-12 100000 cycle
• Mechanical Durability:30000000 cycle
• Connecting Capacity:
  • Flexible with Ferrule 1x 0.5 ... 2.5 mm²
  • Flexible with Ferrule 2x 0.5 ... 1.5 mm²
  • Flexible with Insulated Ferrule 1x 0.5 ... 2.5 mm²
  • Flexible with Insulated Ferrule 2x 0.5 ... 1.5 mm²
  • Flexible 1x 0.5 ... 2.5 mm²
  • Flexible 2x 0.5 ... 1.5 mm²
  • Rigid 1x 0.5 ... 4 mm²
  • Rigid 2x 0.5 ... 2.5 mm²
• Tightening Torque:0.6 ... 0.8 N·m
• Wire Stripping Length:8 mm
• Recommended Screw Driver:
  • Pozidriv 1
  • 0.8 x 4
  • 4.5
• Mounting Position:1 ... 6
• Mounting on DIN Rail:
  • TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
  • TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
• Standards:
  • CAN/CSA C22.2 No.14
  • IEC/EN 63000
  • IEC/EN 61812-1
  • UL 508
