Khởi động mềm ABB PSR60-600-11 (1SFA896112R1100)

Technical Specifications

• Rated Operational Voltage:208 ... 600 V AC
• Rated Control Supply Voltage (Us):24 V AC/DC
• Rated Control Circuit Voltage (Uc):DC Operation 24 V
• Rated Frequency (f):50/60 Hz
• Main Circuit 50 / 60 Hz
• Rated Operational Power - In-Line Connection (Pe):
  • (230 V) 15 kW
  • (400 V) 30 kW
  • (500 V) 37 kW
• Rated Operational Current - In-Line Connection (Ie):60 A
• Service Factor Percentage:100 %
• Overload Protection:Recommended MS495 45 ... 63
• Integrated Electronic Overload:No
• Adjustable Rated Motor Current Ie:No
• Starting Capacity at Maximum Rated Current Ie:4xIe for 6s
• Ramp Time:
  • 0 ... 20 second [unit of time]
  • 1 ... 10 second [unit of time]
• Initial Voltage During Start:40 ... 70 %
• Step Down Voltage Special Ramp:100 ... 60 %
• Current Limit Function:No
• Switch for Inside Delta Connection:No
• Run Signal Relay:Yes
• By-pass Signal Relay:Yes
• Fault Signal Relay:No
• Overload Signal Relay:No
• Signal indication completed start ramp (LED):Green
• Signal indication ready to start/standby ON (LED):Green
• Signal indication running R (LED):Green
• Signal indication ramping up/down (LED):Green
• Number of Starts Per Hour at 3.5*Ie for 7 sec. 50% ON Time 50% OFF Time:10
• Communication:FiledBusPlug(Optional)
• Degree of Protection:IP10
• Terminal Type:Main Circuit: Bars
• Connecting Capacity Main Circuit:
  • Rigid 1x 6 ... 95 mm²
  • Rigid 2 x 6 ... 35 mm²
• Connecting Capacity Control Circuit:
  • 1 x 0.75 ... 2.5
  • 2 x 0.75 ... 2.5 mm²
  • Rigid 1/2 x 0.75 ... 2.5 mm²
• Connecting Capacity Supply Circuit:Rigid 1 x 0.75 ... 2.5 mm²
• Tightening Torque:
  • Control Circuit 0.6 N·m
  • Main Circuit 8 N·m
  • Supply Circuit 0.6 N·m
