KEYSIGHT E3632A DC power supply Single output, dual range (15V/7A or 30V/4A, 105/120W)
Product Details
Manufacturer:
KEYSIGHT
Model:
E3632A
Warranty:
Origin:
Malaysia
Technical Specifications
- Output:
- Range 1: 0-15V / 7A
- Range 2: 0-30V / 4A
- Load and line regulation: <0.01% + 2 mV, <0.01% + 250 μA
- Accuracy at 25 ° C ± 5 ° C:
- Programming: 0.05% + 10 mV and 0.2% +10 mA
- Readback: 0.05% + 5 mV and 0.15% + 5 mA
- Ripple and noise (20 Hz to 20 MHz):
- Voltage: < 350 μVrms/2 mVpp
- Current: < 500 μArms
- Power supply: AC 100-230V, 47-63Hz
- Processing time: <100 ms
- Interface: GPIB and RS232
Package Includes
Import Information
HS Code:
Estimated Import Tax:
0,00
Customs Description
- KEYSIGHT E3632A DC power supply Single output, dual range (15V/7A or 30V/4A, 105/120W)
