Product Details
Manufacturer:
UNI-T
Model:
UTx318
Warranty:
Origin:
Trung Quốc
Technical Specifications
- Technical Data
- Detector type UFPA (Vanadium oxide)
- IR resolution 384×288
- Pixel size 12μm
- Spectral range 8-14μm
- Thermal sensitivity(NETD) ≤40mK
- Lens focal length 18mm/F1.0
- Focus Manual
- Field of view(FOV) 14.6°×11°
- Frame rate ≤50Hz
- Display 0.4”LCOS
- Display resolution 1280×960
- Storage 16GB Internal
- USB Type-C
- IP rating IP67
- Drop proof 2m
- Battery 3.6V/4000mAh Li-ion battery
- Battery operation time ≥8 Hours
- Certificates UL,RoHS,CE,UKCA
- Product size 207.6mm×62mm×62mm
- Product net weight 428g
- Functions
- Digital zoom 2x, 4x / 1.0~4x continuous
- Color palettes 5（Black hot, White hot, Hottest, Ironbow, Rainbow）
- Hot trace √
- Calibration modes Shutter,Background,Auto
- DDE (Digital Detail Enhancement) Details & Edge
- Laser pointer √ (650nm)
- Photo capture √
- PC software analysis √
- Video output MCX interface
Package Includes
Import Information
HS Code:
Estimated Import Tax:
0,00
Customs Description
Ống nhòm ảnh nhiệt UNI-T UTx318 UNI-T UTx318 Thermal Imaging Monocular
