Product Details
Manufacturer:
UNI-T
Model:
UT205A+
Warranty:
Origin:
CHINA
Technical Specifications
- ACA: 1000A / ± (1.5% + 5)
- Dòng khởi động: 600A
- ACV: 1000V / ± (1.0% ＋ 2)
- Tần số ACV: 10Hz ～ 10kHz / ± (1.0% ＋ 5)
- DCV: 1000V / ± (0.7% ＋ 3)
- Điện trở: 40MΩ / ± (0.8% + 2)
- Điện dung: 40mF / ± (4% + 5)
- Tần số: 10.00Hz ～ 10.00MHz / ± (0.1% + 4)
- Kích thước mở kẹp: 45mm
- Nguồn: AAA 1.5V x 2
Package Includes
Import Information
HS Code:
Estimated Import Tax:
0,00
Customs Description
UNI-T UT205A+ AC Clamp Meters (1000AAC, 1000VAC/DC)
UT205A+ 1000A AC clamp meters are reliable and portable tools for electronics and electrical maintenance. Featuring a lightweight and slim design, and backlight for working in dark environments. These meters also feature duty cycle, NCV, MAX/MIN, and Inrush current measurement.
Models: UT205A+, UT206A+
[caption id="_0" align="aligncenter" width="600"]
UNI-T UT205A+ AC Clamp Meters (1000AAC, 1000VAC/DC)[/caption]
● 1000A AC current measurement
● 1000V AC/DC voltage measurement
● 600A inrush current measurement (UT206A+)
● Temperature (UT206A+)
● NCV (UT206A+)
● ACV frequency 10Hz～10kHz
● Jaw opening: 45mm
● Resistance / capacitance / frequency measurement
● Auto range / backlight / low battery indication
● Continuity / diode / duty cycle
● MAX/MIN
● Data hold / flashlight / relative mode
● Auto power off
● CAT II 1000V/CAT III 600V
Applications of UT205A+/UT206A+ 1000A Digital Clamp Meters
